Anybody here know a fast way to convert a Mesh section sketch into a Solid sketch?
Frustrating that F360 can show perfect cross section outline but is incapable of converting it to a solid sketch so it can be manipulated or extruded.
depends on the model. there are a few methods I use. if its a huge model you may want to use another mesh software to reduce the mesh first.
you need to use these tools
in the mesh tab>Create . create a cross section with the " Create Mesh Section Sketch"
The section plane should begin in the center of the mesh body you have selected.
Move the section plane into the correct position for the reference geometry you want.
This will create a sketch in the browser bar. Edit this sketch.
Now in the Sketch> Create use the “Fit Curves to Mesh Section”
Used the tools in this menu to trace the elements of the Mesh Section Sketch that of need for reference.
Now you have a solid sketch that can be extruded and modified .
Let me know if you want a video on this.
2 Likes
Another example with a skull mesh
Here is the F3D for this example
1 Like
YES…Please!!!
Is that a scan of your foot?
2 Likes
Thanks @TinWhisperer . I knew of those, but I was hoping for a simpler methond.
I am trying to do what you did last year taking a 3d print file of a Halloween scene (lamp) and prep it for the table. Lot of detail to have to mouse click around.
Gonna have to fire up Picture Publisher and take a invert image mask.
1 Like
Well conveniently enough the master of fusion YouTube videos just yesterday posted a video on the subject.
There’s not much I can add to this.
3 Likes
Well, that was short and sweet with a lot of useful tips! Thanks for posting!
As always with Kevin’s videos, I’ll have to watch several times, pausing throughout, and doing it along with him. So much info in a short amount of time
3 Likes
Agreed. In the description of the video, he also references two other helpful videos for those of us without the “prismatic” option to work with mesh bodies:
2 Likes
